Description

Specifications:

• Temperature range: –40 to 135°C (–40 to 275°F)
• Maximum temperature that the sensor can tolerate without damage: 150°C
• Typical Resolution:
  • 0.17°C (–40 to 0°C)
  • 0.03°C (0 to 40°C)
  • 0.1°C (40 to 100°C)
  • 0.25°C (100 to 135°C)
• Temperature sensor: 20 kΩ NTC Thermistor
• Accuracy: ±0.2°C at 0°C, ±0.5°C at 100°C
• Response time (time for 90% change in reading):
  • 10 seconds (in water, with stirring)
  • 400 seconds (in still air)
  • 90 seconds (in moving air)
• Probe dimensions:
  • Probe length (handle plus body): 15.5 cm
  • Stainless steel body: length 10.5 cm, diameter 4.0 mm
  • Probe handle: length 5.0 cm, diameter 1.25 cm
